Carriages completely
enclosed for safety
|
|
Aircraft quality cables
rated at 14,500 lbs.
|
|
19" wide runaways
formed with one piece 3/16" non-skid diamond plate
|
|
Power supply available in
12vdc, 110vac, 220vac
|
|
Ten locks stops made from
steel bar stock
|
|
Large 12" x 12"
baseplates for stability
|
|
7,000 lb. lifting capacity
|
|
Easy operation—lock handle
is located by power unit minimizing any bending or squatting
|
|
Locks are spring-loaded,
ensuring a clean release
|
|
All lock rods are threaded
with heim ends for optimal leverage and crisp latching
|
|
37" long steel approach
ramps attached to either end of runways
|
|
Large 3" diameter
cylinder is located safely under runway
|
|
Eight oversized slider
blocks made from ultra-high molecular weight (UHMW) polyethylene,
are self-lubricating, wear-resistant and maintenance-free
|
|
New taller column design
allows parking clearance for most mini-vans and sport utility
vehicles
|
|
Four drop-in stop plates
|
|
Available in Black, Blue and
Red at no extra charge. |
|
Lifetime limited warranty |
|
| Specifications: |
|
| Maximum
capacity |
7,000
lbs. |
| Overall
length (without 37" ramps) |
14'
2.5" |
| Overall
width |
110.75" |
| Height
of columns |
82" |
| Length
of track |
153" |
| Power
pack |
12vdc,110vac,
220vac |
| Runway
width |
18" |
| Rate of
lift to full height |
90
seconds* |
| Maximum
clearance between posts |
99" |
| Maximum
clearance under runways |
68.25" |
| Shipping
weight |
1,500
lbs. |
|
